Leica-Flexline TS 10 TOTAL STATION

Leica-Flexline TS 10 TOTAL STATION Specification

Application
Land Survey, Civil Engineering, Construction Layout

Features
Ergonomic design, large touchscreen, built-in applications, Bluetooth, reflectorless operation

Resolution
0.1 mgon/1

Display Type
5-inch color touchscreen, dual-face

Mounting Type
Tripod mount

Response Time
Instant aiming and rapid measurement

Operating Voltage
7.4V (Li-ion battery)

Measuring Range
up to 3500 m (with prism), up to 500 m (without reflector)

Equipment Type
Total Station

Max Height
200 mm (instrument only, excluding tripod)

Humidity
95% non-condensing

Temperature
-20C to +50C (operating)

Port Size
USB, RS232, Bluetooth

Interface Type
USB, Bluetooth, RS232

Automation Grade
Semi-automatic

Accuracy
1, 2, 3, or 5 (selectable model-dependent)

Power Supply
Li-ion battery, 7.4V / external AC charger

Usage
Outdoor, Survey, Construction Site

Machine Weight
5.0 kg (approx., with tribrach and battery)

Control Mode
Manual and semi-automatic operation

Display
Touchscreen, 800 x 480 pixels

Communication
Wireless Bluetooth Class 1, USB Host/Device

Internal Memory
Up to 2 GB

Distance Measurement
Reflectorless: up to 500 m, with single prism: up to 3500 m

Battery Operating Time
Up to 30 hours (typical for continuous angle measurement)

Laser Plummet
Built-in, adjustable brightness

Instrument Height
200 mm

Guide Light
Yes, integrated guide light for stakeout

Carry Case
Included, rugged transport case

Angle Measurement
Incremental, absolute encoder

Compensator
Dual-axis compensator, 4 range

Data Storage
SD card support, USB flash drive export

Environmental Protection
IP66 Dust and Water Protection

About Leica-Flexline TS 10 TOTAL STATION

Buy the top-ranking Leica-Flexline TS 10 TOTAL STATION today-engineered for dominance across demanding environments. Explore its classic features, including a 5-inch dual-face color touchscreen and guide light, ensuring rapid measurement and staking efficiency. Pick yours for unmatched reliability in land surveying, civil engineering, and construction layout projects. Achieve reflectorless distance measurement up to 500 m and 3500 m with a single prism. Experience up to 30 hours of battery life, ergonomic design, and robust IP66-rated protection. This equipment is delivered with a rugged carry case, internal memory, USB, Bluetooth, and intuitive, semi-automatic operation.

Product Applications & Feature Highlights

The Leica-Flexline TS 10 TOTAL STATION stands out for its specific use in land surveys, general construction layout, and civil engineering tasks. Its versatility allows dominant performance on outdoor projects, delivering precision with selectable accuracy models. The dual-axis compensator, large color touchscreen, and reflectorless measuring up to 500 metres make it ideal for general use in challenging environments, while its ergonomic build and robust protection ensure ongoing reliability across a wide application area.

Sample Availability, Policy & Delivery Information

Premium samples of the Leica-Flexline TS 10 TOTAL STATION may be provided based on supplier policy and customer expenditure. Interested clients are encouraged to contact us regarding the availability of samples and associated terms. Delivery of your selected model is executed promptly, ensuring the total station is safely delivered in a protective carry case. Expect efficient handling and responsive lead times, aligning with high expectations for performance and service quality.

FAQ's of Leica-Flexline TS 10 TOTAL STATION:

Q: How does the Leica-Flexline TS 10 TOTAL STATION benefit construction and surveying projects?

A: The Leica-Flexline TS 10 TOTAL STATION delivers precise, rapid angle and distance measurements, enhancing productivity and accuracy in both construction and land surveying tasks.

Q: What are the main features included in the Leica-Flexline TS 10 TOTAL STATION?

A: Top features include a 5-inch dual-face color touchscreen, reflectorless and prism measurement, dual-axis compensator, ergonomic design, IP66 dust/water protection, Bluetooth, USB interfaces, and semi-automatic operation.

Q: Where can the Leica-Flexline TS 10 be effectively utilized?

A: This total station is ideal for use outdoors on construction sites, civil engineering projects, and general land survey applications, particularly where long-range and reliable performance are necessary.

Q: What is the process for obtaining a sample of the Leica-Flexline TS 10?

A: Interested buyers should contact the supplier to discuss sample availability and relevant sample policies, which may vary depending on order size and client requirements.

Q: How is the Leica-Flexline TS 10 TOTAL STATION powered and how long does the battery last?

A: This instrument is powered by a 7.4V Li-ion battery and can operate continuously for up to 30 hours, making it suitable for long surveying or construction sessions without frequent recharging.
